MB-50

2021-09-30 660


Block Ice and Production Design of MB50:


Item

No.


Design


Weight of Ice and Machine


Size of Ice and Machine

(need consider some space for operate machine, move ice and people walk around)


Ice Model Quantity


Time For Ice

Formed


Time in a Day


Total in a Day


MB50


Design A


20kg


Ice:

100mm×200mm650mm


85pcs


8hours


3times


255pcs of 20kg



Design B


25kg


Machine unit:

1500mm×800mm×2000mm

Tank:

3300mm×1510mm×1120mm

Water cooling:

Cooling Tower:

H1870 mm×2070 mm


67pcs


8hours


3times






Ice:

110mm×300mm×850mm





201pcs of 25kg





Machine unit:

1500mm×800mm×2000mm

Tank:

3300mm×1510mm×1120mm

Water cooling:

Cooling Tower:

H1870 mm×2070 mm







Note:

1. Weight and size of each ice block we can custom made as your requirement.

2. Size of machine is before installation, it is for reference only.

3. We will prepare matched cooling tower for the machine, it will be installed in the outside.

4. It is a completely machine that we offer. It contain main frame, salt water tank (inside the tank

are ice block cans with shelf, on the top of the tank is covers), cooling tower, water pumps, water pipes and water pipe fittings.
